Product Details

Tech specs
Processor
Two 4th Generation Intel® Xeon® Scalable processors with up to 32 cores per processor

Operating System
Canonical® Ubuntu® Server LTS
Microsoft® Windows Server® with Hyper-V
RedHat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®

Chipset
Intel® C741 chipset

Accelerators
Up to 4 x 150 W (Single Width Full Height/Half Length, Low Profile) GPU or up to 2 x 300 W (Double Width Full Height/Full Length)

Memory
DIMM Speed
Up to 4800 MT/s

Memory Type
RDIMM

Memory Module Slots
16 DDR5 DIMM slots

Maximum RAM
RDIMM 1 TB max

Storage
Front Bays
Up to 8 x E3.S NVMe direct drives, 51.2 TB max
Up to 4 x 2.5-inch SAS/SATA or NVMe SSD drives, 61.44 TB max

Storage Controllers
Internal Controllers
PERC H965i, PERC H755, PERC H355, HBA355i

External Controllers
N/A

Software RAID
S160

Internal Boot
Boot Optimized Storage Subsystem (NVMe BOSS-N1): HWRAID 1, 2 x M.2 SSDs
Internal USB

Security
Cryptographically signed firmware
Data at Rest Encryption (SEDs with local or external key mgmt)
Secure Boot
Secured Component Verification (Hardware integrity check)
Secure Erase
Silicon Root of Trust
System Lockdown (requires iDRAC9 Enterprise or Datacenter)
TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
Management
Embedded / At-the-Server
iDRAC9
iDRAC Direct
iDRAC RESTful API with Redfish
iDRAC Service Module

Consoles
CloudIQ for PowerEdge plug in
OpenManage Enterprise
OpenManage Power Manager plugin
OpenManage Service plugin
OpenManage Update Manager plugin

Mobility
OpenManage Mobile

Tools
Dell System Update
Dell Repository Manager
Enterprise Catalogs
iDRAC RESTful API with Redfish
IPMI
RACADM CLI

OpenManage Integrations
Microsoft® System Center
OpenManage Integration with ServiceNow
RedHat® Ansible® Modules
Terraform Providers
OpenManage Integration for Microsoft® System Center
OpenManage Integration with Windows Admin Center
OpenManage Enterprise Integration for VMware® vCenter™
VMware® vCenter™ and vRealize Operations Manager

Power Supplies
1800 W Titanium 200—240 VAC or 240 HVDC, hot swap redundant
1400 W Platinum 100—240 VAC or 240 HVDC, hot swap redundant
1100 W Titanium 100—240 VAC or 240 HVDC, hot swap redundant
1100 W -48 — (-60) VDC, hot swap redundant

Continuous Operation
-5°C to +55°C
Minimum cold boot temperature at ≥ 5°C

Fans
Six cooling fans
All are cold swap fans

Cooling options
Air cooling

Ports
Network Options
1 x OCP 3.0 (optional)
2 x 1GbE LOM

Front Ports
Rear Accessed Configuration
1 x iDRAC Direct (Micro-AB USB 2.0) port
1 x USB 2.0
Front Accessed Configuration
2 x USB 2.0
1 x iDRAC dedicated port
1 x USB 3.0
1 x Serial (Optional, on Slot 5)
1 x VGA
1 x iDRAC Direct (Micro-AB USB) port

Rear Ports
Rear Accessed Configuration
1 x USB 2.0
1 x USB 3.0
1 x iDRAC dedicated port
1 x Serial (Optional, on Slot 5)
1 x VGA
Front Accessed Configuration
N/A

Internal Ports
1 x USB 3.0 (optional)
Slots
PCIe
2 CPU configuration: Up to 5 PCIe slots (4 x16 Gen4/5, 1 x16 LP Gen4)

Video Card
1 x VGA

Bezel
Optional security bezel with dust filter (Dust sensor is available only for Front Accessed configuration systems)

Form Factor
2U rack server

Dimensions & Weight
Rear Accessed configuration
Height:
86.8 mm (3.41 inches)

Width:
482.6 mm (19 inches)

Depth:
448.8 mm (17.6 inches) ear to rear wall
496.3 mm (19.53 inches) with bezel
471.8 mm (18.57 inches) without bezel

Weight:
Max 21.16 kg (46.64 pounds)

Front Accessed configuration
Height:
86.8 mm (3.41 inches)

Width:
482.6 mm (19 inches)

Depth:
572 mm (22.51 inches) with bezel
471.8 mm (18.57 inches) without bezel

Weight:
Max 21.16 kg (46.64 pounds)

Rack Support
Sliding, stab-in rails with optional CMA and SRB for 4-post racks with rack post distance of 470 - 750 mm. These rails also support optional CMA and SRB for 2-post racks.
Sliding, stab-in rails for rugged transit case (MIL 901E certified in (Pelican Custom Rack 25-036329-01) with rack post distance of 425 - 558 mm.

Features & Design

Driving energy efficiencies in large-scale data centres

The Dell PowerEdge XR7620 is designed to maximise value and efficiency in your data centre.

Fits your evolving AI acceleration needs

Systems management and security solutions

OpenManage systems management

Intelligent automation

Built-in security
