Product Details

Tech specs
Processor
1 x 3rd Generation Intel® Xeon® D Scalable processor with up to 20 cores

Operating System
Canonical® Ubuntu® Server LTS
Microsoft® Windows Server® with Hyper-V (support from July'23)
Red Hat® Enterprise Linux
SUSE® Linux Enterprise Server
VMware® ESXi®

Accelerators
Up to 2 x 150W single-width GPU / 1 x 250W double-width GPU

Memory
DIMM Speed
Up to 2933 MT/s

Memory Type
RDIMM and LRDIMM

Memory Module Slots
4 x DDR4 DIMM slots

Maximum RAM
Supports RDIMM 256 GB max, LRDIMM 512 GB max

Storage
8 x M.2 NVMe SSDs on PCIe Add-in card
4 x M.2 NVMe SSDs on M.2 riser module

Storage Controllers
Internal Boot
Boot Optimized Storage Subsystem (BOSS-N1): 2 x M.2 SSDs 480 GB or 960 GB

Security
Cryptographically signed firmware
Secure Boot
Secure Erase
Silicon Root of Trust
System Lockdown (requires iDRAC9 Enterprise or Datacenter)
TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ

Management
Embedded / At-the-Server
iDRAC9
iDRAC Direct
iDRAC RESTful API with Redfish
iDRAC Service Module

Consoles
OpenManage Enterprise
OpenManage Power Manager plugin
OpenManage Service plugin
OpenManage Update Manager plugin

Mobility
OpenManage Mobile

Tools
Dell System Update
Dell Repository Manager
Enterprise Catalogs
iDRAC RESTful API with Redfish
IPMI
RACADM CLI

OpenManage Integrations
BMC Truesight
Microsoft® System Center
OpenManage Integration with ServiceNow
Red Hat® Ansible® Modules
Terraform Providers
VMware® vCenter™ and vRealize Operations Manager

Power Supplies
1800W Platinum 200-240 VAC or 240 HVDC
1400W Platinum 100-240 VAC or 240 HVDC
1100W Platinum 100-240 VAC or 240 HVDC (only for XR4000r)
1100 W DC / -48-(-60) V
With up to 3 Standard (STD) cabled cooling fans with reverse and normal air-flow

Ports
Network Options
4 x 25GbE SFP (max 100 Gb)
4 x 10GbE SFP (max 50 Gb)

Front Ports
1 x iDRAC Direct (Micro-AB USB) port
2 x USB 3.0
1 x Serial port
1 x Mini-DisplayPort
1 x RJ45 iDRAC9 ethernet port

Internal Ports
1 x USB 3.0

Slots
PCIe
2 x16 Gen4 (x16 connector) full height, full length

Chassis
XR4000r and XR4000z

Bezel
Security bezel on XR4000r and XR4000z

Form Factor
Up to two independent, 1U single-width, 1-processor server sled in a XR4000r chassis
One independent, 2U single-width, 1-processor server sled in a XR4000z chassis

Dimensions & Weight
Height: 83.25 mm (3.27 inches)
Width: 167.2 mm (6.58 inches)
Depth: 342.5 mm (13.48 inches)
Weight: 4.69 kg (10.34 pound)

Features & Design

Driving energy efficiencies in large-scale data centres

The Dell PowerEdge XR4520c is designed to maximise value and efficiency in your data centre.

Fits your evolving AI acceleration needs

Systems management and security solutions

OpenManage systems management

Intelligent automation

Built-in security
