Product Details

Tech specs
Processor
One 3rd Generation Intel Xeon Scalable processor with up to 36 cores

Operating System
Canonical Ubuntu Server LTS
Citrix Hypervisor
Microsoft Windows Server with Hyper-V
RedHat Enterprise Linux
RHEL Realtime
SUSE Linux Enterprise Server
VMware ESXi

Chipset
Intel C620 series chipset

Accelerators
Up to two single-width 70 W

Memory
DIMM Speed
Up to 3200 MT/s

Memory Type
RDIMM
LRDIMM
Intel Optane PMem 200 Series

Memory Module Slots
8 DDR4 DIMM slots

Maximum RAM
RDIMM 512 GB
LRDIMM 1 TB
Intel Optane PMem 200 Series 512 GB

Storage
Storage

Front Bays
Up to 4 x 2.5-inch SAS/SATA/NVMe (SSDs) max 61.44 TB

Rear bays
N/A

Storage Controllers
Internal Controllers
PERC H755, PERC H345, HBA355i

External Controllers
PERC H840, HBA355e

Software RAID
S150

Internal Boot
Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2 x M.2 SSDs, USB 3.0

Storage

Drive Bays
Up to 4 x 2.5-inch SAS/SATA/NVMe (SSDs) max 61.44 TB

Rear bays
N/A

Security
Cryptographically signed firmware
Secure Boot
Secure Erase
Silicon Root of Trust
System Lockdown (requires iDRAC9 Enterprise or Datacenter)
TPM 2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ

Management
Embedded / At-the-Server
iDRAC9
iDRAC Service Module
iDRAC Direct

Consoles
OpenManage Enterprise
OpenManage Power Manager plugin
OpenManage SupportAssist plugin
OpenManage Update Manager plugin

Mobility
OpenManage Mobile

Tools
iDRAC RESTful API with Redfish
IPMI
RACADM CLI
System Update Utility
Update Catalogs

OpenManage Integrations
BMC Truesight
Microsoft System Center
RedHat Ansible Modules
VMware vCenter and vRealize Operations Manager


OpenManage connections
IBM Tivoli Netcool/OMNIbus
IBM Tivoli Network Manager IP Edition
Micro Focus Operations Manager
Nagios Core
Nagios XI


Power Supplies
1400 W Platinum AC/240 HVDC
1100 W DC/ -48-(-60) V
1100 W Titanium Mixed Mode AC/100-240 V, DC/240 V
800 W Platinum AC/240 HVDC
800 W DC/-48 V, DC/(-40-(-72))
700 W Titanium Mixed Mode HLAC AC/200-240 V, DC/240 V
Hot plug power supplies with full redundancy option.
Six cold swap fans

Ports
Network ports
4 x 25 GbE SFP+ LOM

Front Ports
Rear Accessed Configuration
1 x iDRAC Direct (Micro-AB USB) port
1 x USB 2.0

Front Accessed Configuration
1 x USB 2.0
1 x iDRAC dedicated port
1 x USB 3.0
1 x Serial
1 x VGA
1 x iDRAC Direct (Micro-AB USB) port

Rear ports
Rear Accessed Configuration
1 x USB 2.0
1 x USB 3.0
1 x iDRAC dedicated port
1 x Serial
1 x VGA

Front Accessed Configuration
N/A

Internal Ports
1 x USB 3.0

Slots
PCIe
3 x PCIe Gen4 slots

Video Card
1 x VGA

Bezel
Optional bezel or security bezel

Form Factor
1U rack server

Dimensions & Weight
Height
Rear accessed configuration
42.8 mm (1.68 inches)
Front accessed configuration
42.8 mm (1.68 inches)

Width
Rear accessed configuration
482.6 mm (19 inches)
Front accessed configuration
482.6 mm (19 inches)

Depth
Rear accessed configuration
400 mm (15.74 inches) ear to rear wall
477 mm (18.77 inches) with bezel
463 mm (18.22 inches) without bezel
Front accessed configuration (no bezel support)
400 mm (15.74 inches) ear to rear wall
463 mm (18.22 inches) without bezel

Weight
Rear accessed configuration
Max 10.7 kg (23.58 lbs.)
Front accessed configuration
Max 10.7 kg (23.58 lbs.)



Rack Support
Sliding, stab-in rails with optional CMA and SRB for 4-post racks with rack post distance of 470 - 750 mm. These rails also support optional CMA and SRB for 2-post racks.

Sliding, stab-in rails for rugged transit case (MIL 901E certified in (Pelican Custom Rack 25-036329-01) with rack post distance of 425 - 558 mm.

Features & Design

Driving energy efficiencies in large-scale data centres

The Dell PowerEdge XR11 is designed to maximise value and efficiency in your data centre.

Fits your evolving AI acceleration needs

Systems management and security solutions

OpenManage systems management

Intelligent automation

Built-in security
